Abbey Bike Tools Hanger Alignment Gauge Complete Tool
Overview
The alignment of the derailleur hanger is now more important than ever, with the constantly expanding rear cog count on modern bikes and the tighter tolerances that the chain and derailleur need to run to. If your hanger is even slightly out, shifting performance can be affected. The HAG helps to avoid this problem in a way that no other tool can.
Key Features
- Achieves a level of precision most hanger tools can't equal
- Tolerances are as tight as .0063mm in some planes, ensuring a low margin of error
- Sliding design, packs down to just 28cm for easy transport, with gauge stick tucking into handle
- Top half rotates 360 degrees to avoid obstacles, with no need to remove and replace the tool
- T-bolt extends past tool to access any hanger
- Brass bushing in head is replaceable, promoting longevity
- Compatible with 26”, 27.5”/650B and 29”/700 wheels
- Tested on a wide range of frames, works with Trek frames with ABP, Specialized frames and Shimano's direct mount rear derailleur fitment
- Paired with Abbey Bike Tools' Lever Setter, can be used to check alignment of brake heads
- Made in Bend, Oregon
Product information
You have 30 days to return your item from when it reaches you
If you wish to return a product under warranty, please see our Saddleback Warranty Information page for more information.
- Free standard delivery (3-5 working days) on orders over £45.
- Standard delivery (3-5 working days) on orders under £45 - £2.99
- Express delivery (1-2 working days) £4.99
For more information on delivery times and prices click here.
The alignment of the derailleur hanger is now more important than ever, with the constantly expanding rear cog count on modern bikes and the tighter tolerances that the chain and derailleur need to run to. If your hanger is even slightly out, shifting performance can be affected. The HAG helps to avoid this problem in a way that no other tool can.
Measuring just 28cm when collapsed, the Hanger Alignment Gauge will fit easily into any travelling mechanic's toolbox. The brass bushing in the head is replaceable, so that you can change it out if it starts getting worn, and it's reamed for smooth T-bolt action.
The handle can spin 360 degrees to avoid common obstacles, like the seat stay, rack stays and fenders, while the gauge stick and handle top are both threaded, so that the stick can be locked to achieve a consistent measurement as you move the point of reference around the rim. That stick not only carries a scale, so that you can be precise with your measurements, but tucks handily into the top of the head when it's not needed.
Meanwhile, tight tolerances within the handle limit play, so that unlike with other hanger tools, the HAG remains solid at its full extension, ensuring an exceptionally low margin of error in your alignment and better drive train action. When collapsed, it can double as a superb pry bar, allowing you to tug incorrectly aligned hangers back into place there and then.
